Hard Dog Mazda Miata Roll Bar M3 Hard Core
M3H1D, M3H2D
Here at Hard Dog we offer an extensive line of Roll Bars for the 2006 - 2015 3rd Generation MX-5. All built from heavy wall tubing, these bars are a serious upgrades from the stock NC equipment.
Removable Hard Top ONLY. The M3 Hard Core requires removal of the soft top and interior panels behind the seats to allow greater main hoop width and improved rearward brace geometry.
The main hoop is mounted to the unibody structure behind the seats with large main hoop mounting plates bolted to the existing stock hoop attachment points and through the bulkhead into reinforcment plates installed inside the chassis. Additional rearward support is provided by 2 rear braces w/ large 3/16" mounting and back-up reinforcement plates anchored with grade 8 bolts and self locking nuts.
Stock seats and belts can be retained.
Available with a Single Diagonal in the plane of the main hoop or Double Diagonals to the rearward braces.
An integral harness bar is standard equipment.
Removable Hard Top ONLY. The M3 Hard Core requires removal of the soft top and interior panels behind the seats to allow greater main hoop width and improved rearward brace geometry.
The main hoop is mounted to the unibody structure behind the seats with large main hoop mounting plates bolted to the existing stock hoop attachment points and through the bulkhead into reinforcment plates installed inside the chassis. Additional rearward support is provided by 2 rear braces w/ large 3/16" mounting and back-up reinforcement plates anchored with grade 8 bolts and self locking nuts.
Stock seats and belts can be retained.
Available with a Single Diagonal in the plane of the main hoop or Double Diagonals to the rearward braces.
An integral harness bar is standard equipment.
Shipping: -Flat rate shipping costs from manufacturer-
Pricing:
$885.00
Description
M3 Hard Core Features:
Meets NASA HPDE and SCCA Time Trials and Solo 1 requirements
Allows full seat travel and tilt
Full interior height and width
Removable Hard Top ONLY. Not compatible with any soft top
Durable black powdercoat finish
Constructed of highest quality 1.75" diam x .120" wall drawn over mandrel tubing
One or two main hoop diagonal braces available
All configurations include an integral harness bar
Complete hardware kit w/ grade 8 bolts and self locking nuts
Due to the additional width and rearward brace angles, the M3 Hard Core is not compatible with the soft top or interior panels behind the seats
Roll Bar Accessories:
Stitched vinyl or leather covers w/ our NEW custom formed high density padding by BSCI
SFI approved high density and traditional foam padding
Meets NASA HPDE and SCCA Time Trials and Solo 1 requirements
Allows full seat travel and tilt
Full interior height and width
Removable Hard Top ONLY. Not compatible with any soft top
Durable black powdercoat finish
Constructed of highest quality 1.75" diam x .120" wall drawn over mandrel tubing
One or two main hoop diagonal braces available
All configurations include an integral harness bar
Complete hardware kit w/ grade 8 bolts and self locking nuts
Due to the additional width and rearward brace angles, the M3 Hard Core is not compatible with the soft top or interior panels behind the seats
Roll Bar Accessories:
Stitched vinyl or leather covers w/ our NEW custom formed high density padding by BSCI
SFI approved high density and traditional foam padding
